This model offers networking capabilities and can serve as the hub of a home entertainment network that’s connected to the Internet. Its powerful networking capabilities provide enjoyment of thousands of free Internet radio stations worldwide and full ac...

This model offers networking capabilities and can serve as the hub of a home entertainment network that’s connected to the Internet. Its powerful networking capabilities provide enjoyment of thousands of free Internet radio stations worldwide and full access to free and paid music streaming services such as Pandora, vTuner, Rhapsody, SiriusXM Internet Radio and Napster. This model is also Windows 7 and DLNA 1.5 certified which allows access to music files on any computer or local NAS drive content available on the home network.

A USB port on the front panel provides convenient connection for your iPod/iPhone, which also charges when connected. Because the digital signal from the iPod/iPhone is transmitted directly to the AV Receiver, noise interference is minimized and sound quality is much better.

The RX-V871 AV Receiver lets you use the Yamaha AV Controller app, a free download from the iTunes App Store or Android Market to control power on/off and volume, select input and DSP modes and operate other functions from an iPhone, iPad and other iOS devices or with an Android device.

This AV Receiver will upscale video signals up to 1080p. This means a much better picture with HDTVs capable of 720p, 1080i or 1080p resolution.

3D means the receiver can handle 3D signal data. The Audio Return Channel function enables data to be sent and received via the same HDMI cable, so you can hear the sound from the TV via a single HDMI cable, with no need for an extra optical cable.

In ordinary deinterlacing, pixels in areas of movement are interpolated by upper and lower ranges. This causes jaggies in diagonal lines. Edge adaptive deinterlacing detects the direction of the line and interpolates the pixels optimally.

Yamaha’s latest Graphical User Interface (GUI) has a high resolution display with clear, easy-to-use menus and also includes a selectable Status Bar that shows input source, volume level, DSP mode and audio format. The GUI provides a choice of six languages: English, French, German, Japanese, Russian and Spanish, and can be displayed over both normal and 3D pictures.

CINEMA DSP 3D provides a wide, high and dense sound field. HD Audio format decoding lets you enjoy HD Audio sources. Virtual Presence Speaker delivers 3-dimensional sound without actual use of presence speakers. The actually measured sound field data contain the information of the height of the sound images. CINEMA DSP 3D mode achieves the reproduction of the accurate height of the sound images so that it creates the accurate and intensive stereoscopic sound fields in a listening room.

The Four SCENE buttons make operating the receiver easier than ever. They are initially set to default settings for BD/DVD Viewing, CD Disc Listening, TV Viewing and Radio Listening. Pressing a SCENE button will automatically launch a number of operations that initiate play of the source controlled by that button. Other SCENE settings are also available, such as iPod Listening, SiriusXM Listening [model dependent], TV Sports Viewing and Action Game Playing. Browsing and selecting the settings is quickly accomplished by changing Input via the front panel and watching the on-screen display. The settings can be selected for one-time use, or they can replace the original default settings. The SCENE names can be changed also.

In addition to the large number of HDMI inputs on the rear panel, there is also one on the front panel. This gives you a convenient way to quickly plug in a digital camera or camcorder for highest quality pictures.

Another benefit of HDMI is the availability of CEC (Consumer Electronics Control) functionality. When the unit is connected to a CEC compatible TV, it will turn on and off together with the TV, and you can use the TV remote to control the volume. CEC also provides advanced functionality with other components. For example, you can use the receiver’s remote unit to control player functions like Skip and Stop.

＊All connected devices must be HDMI CEC compatible. Some CEC compatible TVs/players may not work.

When the AV Receiver is in HDMI Standby Through mode, the input source (Blu-ray™ Disc player, game console, etc.) for viewing on the monitor can be changed via the remote control. There’s no need to turn on the AV Receiver in order to switch sources.

YPAO analyzes the room acoustics and adjusts various audio parameters for optimum sound from your listening position, and lets you set up to eight positions. It’s like having a professional installer calibrate your system.

Intelligent Amp Assign automatically assigns amplifier channels to certain speakers, depending on what functions are selected. For example, in a 7.1-channel system, when Zone 2 is off, all 7.1 channels will be used in the Main Zone. However, when Zone 2 is on, power to the two Surround Back channels will be directed to the two speakers in Zone 2, and the Main Zone will receive 5.1 channels of power. Similarly, when CINEMA DSP 3D is on, the two Front Presence speakers will be powered and not the two Surround Back speakers. When CINEMA DSP 3D is off, this situation is reversed. Thanks to Intelligent Amp Assign, there’s no need to switch the speaker cables on the rear of the receiver—one more way Yamaha makes your life a little easier.

When music is encoded into a digitally compressed format like MP3, the frequency response suffers. Yamaha’s Compressed Music Enhancer employs sophisticated digital signal processing using exclusive algorithms to restore what was lost, so the music always sounds the way it should.

Adaptive DRC automatically adjusts the dynamic range of the sound according to the volume level. This ensures that you hear clear dialogue and vocals, and all sound effects at comfortable levels. There is no need to adjust the volume level as you listen; everything from whispers to big explosions will be heard clearly and comfortably at the same volume setting. It also tones down loud TV commercials, and is ideal for low-volume, late-night listening, when you do not want to disturb others.

• Zone 2 on/off and control on front panel
• Zone sleep and system sleep
• Remote input/output
• Programmable +12V trigger output

Yamaha makes its receivers eco-friendly with a low standby power consumption of 0.1W (2W in HDMI Standby Through mode).

Auto Power Down lets you save energy by selecting to turn off the power after 4, 8 or 12 hours.

Yamaha optional docks make it easy to enjoy your favorite music from your iPod or iPhone, with or without cables. Select from of the following models:
yAired Wireless Dock System YID-W10
Universal Dock for iPod/iPhone YDS-12
Bluetooth® Wireless Audio Receiver YBA-10

• HD Audio format decoding: Dolby TrueHD and DTS-HD Master Audio; Dolby Digital Plus and DTS-HD High Resolution Audio
• Discrete amp configuration
• Selected high quality parts to achieve optimum audio performance
• Pure Direct for HD Audio and video enjoyment
• Low jitter PLL circuitry helps optimize sound imaging
• Detachable Power Cable for easier installation (also allows cable upgrade)
• Assignable amplifiers for bi-amp connection
• Intelligent assignable amplifiers for Surround Back - Front Presence or Zone 2

• 4Kcompatible HDMI: 8 inputs (1 on front) and 2 output
• Supports Deep Color (30/36 bit), x.v.Color, 24Hz Refresh Rate and Auto Lip-Sync compensation
• Multi-cadence (incl. 3-2 pull-down) detection

• DLNA 1.5 certified
• SIRIUS Satellite Radio ready
• Audio input assign capability for HDMI and component video input
• iPod/iPhone compatibility with optional YDS-12 Universal Dock
• Wireless connection for iPod/iPhone with optional YID-W10
• Bluetooth (A2DP) compatibility with optional Yamaha Bluetooth® Wireless Audio Receiver YBA-10
• iPod/iPhone song titles displayed in English and Western European languages on the front panel and on-screen display
• Dialogue Lift
• Audio Delay for adjusting Lip-Sync (0-250ms)
• Preset remote unit
• Background video feature (for tuner, Net, USB and SIRIUS Satellite Radio)

• Virtual Presence Speaker function for CINEMA DSP 3D surround without Front Presence Speakers
• Adaptive DSP Level
• SILENT CINEMA and Virtual CINEMA DSP
