Soundscape Product Listing
TRUAUDIO
Amplifiers
TruAudio power amplifiers come in different shapes and sizes.
For multi-room audio, we offer two 12 channel amplifiers designed just for
this purpose.
With a Great looking front panel and versatility of electronics hidden inside,
these models offer tons of features and power to enhance any installation.
Also available is model SA-250, an amplifier designed for
subwoofer use. With a simple switch, this unit goes from 2 channel power
to a high-power subwoofer amp allowing only low, bass frequencies to pass
though.
When in the 2 channel setting this model can be used to drive all kinds
of different speaker scenarios depending on the application.
12 Channel Amps
MR-1260
Soundscape Price:$2000 each
add $20 for Rack kit.
12
channel, 6 zone power amplifier 66 watts per channel x 12 Flexible power amp
for any multi-room audio system Individual zone inputs or Global input 12 volt
trigger remote input Pass-through RCA's jacks for connecting additional amps
All needed certification Rack mount or non-rack mount available Available in:
black
- Design: Multi-ch. Power Amplifier
- Channels: 12 ch., 6 zone
- Power output, continuous: 66 watts per ch. @ 8 ohm 85 watts per ch. @ 4
ohm
- Bridged Power output: 130 watts per ch. @ 8 ohm
- Frequency range: 18Hz - 50k Hz @ - 2 dB
- Total Harmonic distortion: 0.05% @ 20Hz-25k Hz (8 ohm)
- Signal to noise ratio: minus 100 dB
- Dampening factor: greater than 400dB
- Input Impedance: 20k ohm
- Additional features: 12volt trigger input
- Global inputs Pass-through RCA outputs
- Tooless "snap-down" connectors
- Certification: UL, CE, CAN/CSA
- Dimensions: 5 7/8" H, 17" W, 17 1/2" D
- Actual Amplifier weight: 49 lbs
- Shipping weight: 60 lbs
MR-1235
Soundscape Price:$1200 each
add $20 for Rack kit.
12
channel, 6 zone power amplifier 38 watts per channel x 12 Flexible power amp
for any multi-room audio system Individual zone inputs or Global input 12
volt trigger remote input Pass-through RCA's jacks for connecting additional
amps All needed certification Rack mount or non-rack mount available Available
in: black
-
Design: Multi-ch. Power Amplifier Channels: 12 ch., 6
zone
-
Power output, continuous: 38 watts per ch. @ 8 ohm 47
watts per ch. @ 4 ohm
-
Bridged Power output: 73 watts per ch. @ 8 ohm
-
Frequency range: 20Hz - 25k Hz @ - 2 dB
-
Total Harmonic distortion: 0.05% @ 20Hz-25k Hz (8 ohm)
-
Signal to noise ratio: minus 100 dB
-
Dampening factor: greater than 400dB
-
Input Impedance: 20k ohm
-
Additional features: 12volt trigger input
-
Global inputs Pass-through RCA outputs
-
Tooless "snap-down" connectors
-
Certification: UL, CE, CAN/CSA
-
Dimensions: 4" H, 17" W, 13 3/4" D Actual
-
Amplifier weight: 34 lbs
-
Shipping weight: 39 lbs
SUBWOOFER AMP
SA-250
Soundscape Price:$700 each
add $20 for Rack kit.
2 channel stereo power amplifier 140 watts per channel x 2 Switching
allows for 2 channel amp or mono subwoofer amp 12 volt trigger remote input.
Pass-through RCA's jacks for connecting additional amps All needed certification
Rack mount or non-rack mount available Available in: black
- Design: Power Amplifier Channels: 2 ch. or bridgeable to mono
- Power output, continuous: 100 watts per ch. @ 8 ohm 140 watts per ch. @
4 ohm
- Bridged Power output: 200 watts per ch. @ 8 ohm
- Frequency range: 20Hz - 25k Hz @ - 2 dB
- Total Harmonic distortion: 0.05% @ 20Hz-25k Hz (8 ohm)
- Signal to noise ratio: minus 100 dB
- Input Impedance: 20k ohm
- Additional features: 12volt trigger input
- Pass-through RCA outputs Binding posts outputs
- Certification: UL, CE, CAN/CSA
- Dimensions: 4" H, 17" W, 13 3/4" D
- Actual Amplifier weight: 35 lbs
- Shipping weight: 40 lbs
