Soundscape Product Information

---

Easy-to-install steel frames, designed to be as dependable and they are attractive.

All frames include:

• Four steel contoured corner posts with printed “U” spaces and rear cable management punch-outs
• Top Panel with either no fans, two fans, or four fans pre-installed
• Versatile bottom panel designed to be stand alone, accommodate casters, or secure onto a slide out system

Complete slide-out solution for easy access to rear cables and equipment.

Features Include:

• 60 Degree turning radius to either right or left
• 450 lb. weight capacity with proper weight distribution
• Optional cable management system in rear
• Allows for off-site integration
• Attaches securely and easily to the rack frame’s bottom panel
• Optional cover available for improved aesthetics
• Optional RackJack service stand adds support and stability

Note: Adds 4" to overall height of rack frame

Tool-less installation for a no-headache finishing touch.
Includes 2 steel panels with push-tab installation

Sturdy, tinted glass or plexiglass doors for a sophisticated finish.
Glass door installs in 20U and 28U models Plexiglass door designed for 36U and 44U models.
Includes mounting hardware and handle.

UL approved, 115V, 3U Panel with two 4.5” 30db fans for efficient rear ventilation

Features Include:

• Smooth, quiet design Each panel comes complete with fans and grills installed
• Includes fan guard, screws, power cord and plug
• Free Air CFM: 55

Sturdy, easy-to-install shelves for non-rackmountable equipment

• Vented panels for improved heat dissipation
• Multiple cable management holes punched at rear of each shelf
• Accommodates equipment up 17-7/32 wide
• L-Brackets can be installed in vent slots for better securing of equipment
• For heavier equipment, shelf-support frames are recommended (R-SHELFSUP)

Steel support frames for universal equipment shelves

• Mounts on inside of extrusion posts
• Features cable management holes large enough for power cord pass-through

Steel powder-coated panels for improved air flow Flanged for extra support 10-Panel master packs are available upon request

• Flanged for extra support
• 10-Panel master packs are available upon request

Thin angled slots for a great look with tremendous results

• Limits viewing of internal components for improved aesthetic appearance
• Flanged for extra support
• 10-Panel master packs are available upon request

Tightly punched for maximum airflow and concealment of internal cabling

• Limits viewing of internal components for improved aesthetic appearance
• Flanged for extra support
• 10-Panel master packs are available upon request

Versatile component drawers for easy storage

• Black powder coat finish
• Easy-grip handle
• Great for storing manuals, DVDs, remotes, etc.

U-Bar: Unique horizontal cable troughs with plenty of tie-down space

• Unique FatCat design
• Installs on rear extrusion posts
• Sells in easy to use 4-Pack

Lacer Bar: Horizontal lacer bar for easy cable tie-down

• Installs on rear extrusion posts
• Sells in easy to use 5-Pack

Screws:

• Standard 10-32 rack screws with self-guiding pilot points
• Sold in plastic bottles of 100 pieces
• Includes nylon washer

L-Bracket:

• L-Brackets for universal shelves
• Installs easily in the vented slots of Universal Shelves
• Keeps shorter equipment from recessing into the rack
• Sold in plastic bottles of 20 pieces

Casters:

• Durable, easy-to-roll casters.
• Supports up to 450 lbs.

Caster Cover:

• Metal cover to conceal casters on bottom of rack.
• Includes installation hardware.

Four connection ground for electrical safety Mounts easily into bottom panel
