The new Quicksilver Full Preamp achieves maximum sound quality with minimal signal paths, minimal switching, and no transistors, regulators or circuit boards. Its massive power supply is housed in a subchassis within the main preamp allowing tremendous dynamic range and transient attack without the limitations of a separate power supply. The output impedance is so low that it will drive 30 ohm headphones directly without the use of a transformer or headphone amplifier. The internal phono stage provides analog enthusiasts state-of-the-art disc playback from a circuit that uses both active and passive RIAA eq.
Price $3900. Price for 230 volt $4100.
Instruction Manual
Specifications
| Power Output | 20 watts into any load from 2 to 8 ohms |
| 1 Watt Bandwidth | 1.5 Hz to 60 KHz |
| Power Bandwidth | 15 Hz to 30 KHz |
| Peak Power | 40 watts per channel |
| Damping Factor | 10 with 8 ohm load |
| Input Impedance | 50 Kohms |
| Tube Complement | Eight 6BQ5 , Two 12DW7 |
| Chassis | Carbide Black |
| Dimensions | 6″H, 11″D, 15″W |
| Weight | 33 lbs. |
| U.S. Warranty | 3 years parts and labor & 90 days for tubes |
| |
|
We accept
over the phone or by E-mail.
ORDERING BY PHONE
If there is no authorized dealer in your area you can order directly from Soundscape.
(707) 337-3355
Last Update: December 25, 2017
